Product Description:
Transparent Display come with a friendly design, it makes a good ideal for entertainment venues the modules are modular and easy to form a big LED screen area. This exciting product not only suits the
| • High transparency: up to 65% on transparency makes the led bulbs almost invisible above a specific distance on screen. |
| • Flexible installation methods for various projects |
| • Light-weighted for single person tools free installation |
| • No need for any changing on building structure |
| • High light transmittance: lights on the stage can easily get through screens |
| Item |
P3.91-7.81 |
P5.2-10.4 |
P7.81-15.625 |
| LED |
Outdoor SMD 1921 |
Outdoor SMD 2727 | Outdoor SMD 3535 |
| Pixel Density (pixel / m2) |
32768 |
18432 | 8192 |
| Module Size (mm) | 250 x 250 | 250 x 250 | 250 x 250 |
| Cabinet Size (mm) |
500 x 1000 |
500 x 1000 |
500 x 1000 |
| Cabinet Material |
Acrylic, Sheet Metal, Aluminum, Stainless Steel |
||
| Transparency |
60% |
65% |
70% |
| Brightness |
>2200nits |
>4000nits |
>4500nits |
| Refresh Rate |
>1920Hz |
>1920Hz |
>1920Hz |
| Scan Mode |
1/16 |
1/16 |
1/4 |
| Max Power |
400W/m2 |
||
| Avg Power |
150W/m2 |
150 W/m2 | 180 W/m2 |
| Driver IC |
Common |
||
| Installation Way |
Hanging or Stacking |
||
| Maintenance |
Rear Service |
||
| Color Scale |
256 level |
||
| Working Voltage | DC 5V | ||
| Grey Level | 12 - 16 bits | ||
| IP Rating | IP43 | ||
| Viewing Angle | 140 | ||
| Voltage Input | AC95V - 240V | ||
|
Working Environment |
Temperature: -10-40, Humidity 10% - 90% RH | ||
| Life Span (Hour) |
100,000 |
||
